    Reliable Industrial Tool for Precision and Power
    Portable without sacrificing durability.
Manual Chain Hoist

TOYO manual chain block model TCB are for heavy duty use with long lasting reliability. High strength steel body and gear case are built to be durable for rugged needs of construction, mechanical and maintenance rigging. We have TCB with a lifting capacity of 500 kgs to 50,000 kgs. We use grade 80 alloy steel load chains. Made with Japanese design and technology, the guide plate helps to avoid slippage of load chain during usage versus the conventional guide rollers. Toyo chain hoist hooks are forged heat treated steel. The top hook is used to fix the hoist to the anchor point and bottom hook is the load hook, this is raised and lowered by simply pulling down the hand chain. TCB is being produced from first grade components which ensure maximum durability, rough and tough usage and longer service life. TCB hoists are economical and practical choice for efficient and trouble-free service. Product is widely used for lifting loads they can be used along with manual push trolley also. The products are proof load tested and supplied with a test certificate and user manual.

    • Product features

      With its compact design, manual chain hoist is ideal for light weight robust construction. It comes with an automatic dual pawl breaking system. It has a double cover protection to ensure smooth operation. The manual chain hoist has a capacity that ranges from 0.5T to 50T. With its distinct features, heavy loads can be lifted with minimum effort. The galvanized zinc plating protects the chain hoist from corrosion and also features heavy-duty forged hooks which are fitted with safety latches as per standards. Consisting of high quality 80 alloy load chain, sealed bearing and extra thick asbestos free friction discs, this hoist is ideal equipment for construction. The product complies with the EC Council Directive 2006/42/EC, Machinery.

    • Characteristics

      • Capacity range from 0.5T to 50T.
      • Automatic double pawl breaking system.
      • Double brake cover protection.
      • Light weight robust construction.
      • Low effort to lift maximum load.
      • Extra thick asbestos free friction discs
      • Fully forged hooks are fitted with safety latches as standard.
      • Galvanized  hand chain as standard.
      • The hoist is fitted with high grade 80 alloy load chain with T8 Mark as per EN818-7
      • Compiles with EC Council Directive 2006/42/EC, Machinery.
      • Confims to EN 13157 and in accordance to ASME Standards
